CLEAN-EFF01 Mop Cleaning Ability Test

The CLEAN-EFF01 Cleaning Efficacy Tester is a cutting-edge solution designed to assess the cleaning performance of a wide range of cleaning materials, including cleaning cloths, floor mops, mopping rags, and more. This advanced instrument simulates real-world cleaning conditions, providing valuable insights into the efficacy of cleaning products used on various surfaces, such as tiles, wooden floors, and glass. Whether you are testing consumer-grade cleaning cloths or industrial-grade mopping systems, the CLEAN-EFF01 offers a comprehensive and reliable method for evaluating cleaning performance.

Introduction to the Cleaning Efficacy Tester

The CLEAN-EFF01 Cleaning Efficacy Tester is a cutting-edge solution designed to assess the cleaning performance of a wide range of cleaning materials, including cleaning cloths, floor mops, mopping rags, and more. This advanced instrument simulates real-world cleaning conditions, providing valuable insights into the efficacy of cleaning products used on various surfaces, such as tiles, wooden floors, and glass. Whether you are testing consumer-grade cleaning cloths or industrial-grade mopping systems, the CLEAN-EFF01 offers a comprehensive and reliable method for evaluating cleaning performance.

Applications of the Cleaning Efficacy Tester

Cleaning Materials Testing

The CLEAN-EFF01 Cleaning Efficacy Tester is essential for manufacturers and quality control professionals in industries such as home cleaning, hospitality, healthcare, and industrial applications. It is perfect for testing a variety of cleaning materials, including microfiber cloths, floor mops, and other fabric-based cleaning products. The tester allows you to simulate typical cleaning actions, ensuring your cleaning products perform effectively across different environments.

Surface Testing

This versatile tester can be used to simulate cleaning actions on a variety of surfaces. It replicates real-world cleaning performance on surfaces like tiles, glass, and wood. The machine allows users to test cleaning materials under various conditions, ensuring they meet quality and effectiveness standards required for different surfaces.

Industry Relevance

The CLEAN-EFF01 is suitable for industries where cleaning efficiency is paramount, such as the hospitality industry, food production, pharmaceuticals, and healthcare. It is ideal for companies that need to assess the cleaning power of their materials before distribution, ensuring consistency and reliability for end users.

Significance of the Cleaning Efficacy Tester

Importance in Quality Control

The CLEAN-EFF01 Cleaning Efficacy Tester plays a crucial role in the quality control process. By simulating the real-world application of cleaning materials, it allows manufacturers to accurately assess the cleaning effectiveness of their products. This process helps improve the quality of cleaning materials, ensuring they meet industry standards for performance and durability.

Enhancing Production & Development

Using the CLEAN-EFF01, manufacturers can enhance product development by gaining valuable insights into how different cleaning materials perform under standardized testing conditions. This feedback helps optimize product formulations, improve design, and refine cleaning processes. Furthermore, the tester aids in reducing labor costs by automating the testing process and delivering consistent, repeatable results.

Test Methods with the CLEAN-EFF01 Cleaning Efficacy Tester

The CLEAN-EFF01 employs a simple yet effective testing methodology.

  1. Test Setup: The sample cleaning cloth or mop is securely fastened to an aluminum or plastic frame. This frame is then positioned vertically on the mobile arm of the tester.
  2. Simulating Cleaning Actions: The sample is aligned to ensure its surface fully engages with the target surface, which may include materials like tiles, glass, or wood. The operator can manually regulate the applied pressure, adjust the movement speed, and control the cycle count to simulate different cleaning conditions.
  3. Test Cycles: Once the designated number of cleaning cycles is completed, the sample is analyzed based on various performance parameters, such as surface cleanliness, wear, and effectiveness.

Technical Features of the Cleaning Efficacy Tester

  • Control System: The CLEAN-EFF01 is operated through a sophisticated PLC (Programmable Logic Controller) and a user-friendly HMI (Human-Machine Interface) screen, making it easy for operators to set up and monitor tests.
  • Precision & Durability: Built to withstand industrial use, the CLEAN-EFF01 features robust construction for long-lasting performance. The system’s design ensures stability during long testing cycles, delivering high precision results every time.
  • High-Speed Performance: Equipped with a fast-speed linear guide, the tester ensures both high-speed movement and precise accuracy, providing reliable results in a short amount of time.
  • Adjustable Test Parameters:
    • Speed Range: 1~27,000 mm/min (adjustable) for a wide range of test conditions.
    • Speed Accuracy: 1 mm/min for highly precise control of movement and test conditions.
    • Test Cycles: Allows for testing up to 20,000 cycles to evaluate the long-term performance and durability of cleaning materials.
    • Moving Distance: 600mm ensures compatibility with a variety of materials and test setups.
  • Power Supply: The tester operates on a standard power supply of 110~220V, making it suitable for use in different regions and environments.

Key Specifications

Parameter Value
Speed 1~27,000 mm/min (adjustable)
Speed Accuracy 1 mm/min
Test Cycles 1~20,000 cycles
Moving Distance 600mm
Power Input 110~220V

Why Choose CLEAN-EFF01 Cleaning Efficacy Tester?

The CLEAN-EFF01 Cleaning Efficacy Tester is designed to provide the most reliable and repeatable results for cleaning performance testing. Its combination of precision, flexibility, and durability makes it the ideal solution for testing a wide variety of cleaning materials and ensuring they meet the necessary quality standards. The user-friendly interface, high-speed performance, and adjustable parameters allow for tailored testing, making it suitable for various industries, from hospitality to healthcare and beyond.

Applications in Industries

  • Packaging: Ensures that cleaning materials used for packaging meet hygiene and performance standards.
  • Food & Beverage: Ideal for testing cleaning materials used in food processing and packaging environments.
  • Textiles: Evaluates the cleaning efficiency of textile-based cleaning materials used in various industries.
  • Pharmaceuticals & Healthcare: Tests the effectiveness of cleaning materials used in cleanroom environments and medical facilities.

The CLEAN-EFF01 Cleaning Efficacy Tester is an essential tool for manufacturers and quality assurance teams looking to ensure their cleaning products meet the highest standards. By replicating real-world cleaning conditions, the tester provides accurate, repeatable results that help improve product quality, reduce labor costs, and optimize product development. Contact Cell Instruments today to learn more about how the CLEAN-EFF01 can enhance your cleaning material testing process.
